BERGMAN 560D Mechanical Seal 17mm 18mm 20mm for Rotary Pumps
| Place of Origin | CN:GUANGZHOU |
|---|---|
| Brand Name | BERGMAN |
| Model Number | 560D |
| Minimum Order Quantity | 10 |
| Price | $6-10 |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Size | 17mm 18mm 20mm | Model | 560D |
|---|---|---|---|
| Pressure | ≤ 0.3mpa | Temperature | ≤ -20°C-70°C |
| Line Speed | ≤ 5m/s | Face Material | CAR SIC |
| Seat Material | CER SIC | Secondary Seal | NBR VITON |
| Metal Parts | SS304 SS316 | Shaft Size | 25/30, 30/35, 40/45, 45/50 |
| Max Temperature | -20°C-120°C | Max Line Speed | ≤ 10m/s |
| Standard Sizes | 14/15/16mm, 17/18/19mm, 20/25/30mm, 35/40/45mm, 50/60/70mm | O-ring Material | NBR VITON |
| Application Type | Rotary Pump | ||
| Highlight | BERGMAN 560D mechanical seal for rotary pumps,17mm mechanical seal for rotary pumps,20mm pump mechanical seal with warranty |
||
Product Description
ED 560D-17mm/18mm/20mm High-Quality Mechanical Seal for EBARA Kawami WQ Submersible Pumps
Product Specifications
| Attribute | Value |
|---|---|
| Size | 17mm, 18mm, 20mm |
| Brand | BERGMAN |
| Model | 560D |
| Application | Rotary pumps (WQ submersible pumps) |
| Pressure Rating | ≤ 0.3MPa |
| Temperature Range | -20°C to 70°C (depends on O-ring material) |
| Line Speed | ≤ 5m/s |
| Materials | CAR SIC face, CER SIC seat, NBR/VITON secondary seals, SS304/SS316 metal parts |
| Certification | ISO9001-2015 |
| Service | OEM customization available |
Product Description
The ED 560D mechanical seal is designed for EBARA, Southern, Hejian, and most WQ submersible pumps. Available in multiple sizes (13-70mm) to fit various shaft dimensions.
Key Features
- Premium materials: Tungsten carbide, silicon carbide, carbon graphite, alumina
- High-quality rubber seals, PTFE seals, and O-rings
- Compatible with major international brands (John Crane, AES, etc.)
- 2000+ sqm warehouse with large inventory for fast delivery
- Factory-direct pricing with excellent quality control
- OEM customization services available
Product Images
Applications
Widely used in pipeline pumps, centrifugal pumps, sewage pumps, and chemical pumps across industries including petroleum, chemical processing, aerospace, pharmaceuticals, food processing, and agricultural irrigation.
Company Profile
Guangzhou Bogman Mechanical Seals Co., Ltd. (established 2019) specializes in mechanical seals with over 20 years of industry experience. Our 2000+ sqm warehouse in Guangzhou ensures efficient logistics and quick delivery. We maintain ISO9001:2015 certification and offer comprehensive sealing solutions.
Production Capabilities
- Modern machine tools and dust-free workshops
- Rigorous inspection and pressure testing for every seal
- Assembly line production for consistent quality
- Regular participation in Guangzhou Import/Export Fair
Frequently Asked Questions
Q: Are you a factory or trader?
A: We are a production factory with our own international trade department.
Q: What is your delivery time?
A: Stock items ship immediately. Custom orders require 10-25 days depending on quantity.
Q: Do you provide samples?
A: Samples are available with cost refundable against future orders.
Q: Can you customize products?
A: Yes, we welcome OEM and custom mechanical seal solutions.
